Model Number
|
RSM130-8-430M
|
RSM130-8-435M
|
RSM130-8-440M
|
RSM130-8-445M
|
RSM130-8-450M
|
|
Rated Power in Watts-Pmax(Wp)
|
430
|
435
|
440
|
445
|
450
|
|
Open Circuit Voltage-Voc(V)
|
44.36
|
44.61
|
44.85
|
45.09
|
45.33
|
|
Short Circuit Current-Isc(A)
|
12.35
|
12.42
|
12.50
|
12.57
|
12.65
|
|
Maximum Power Voltage-Vmpp(V)
|
36.94
|
37.14
|
37.34
|
37.54
|
37.74
|
|
Maximum Power Current-Impp(A)
|
11.65
|
11.72
|
11.79
|
11.86
|
11.93
|
|
Module Efficiency (%)
|
20.7
|
21.0
|
21.2
|
21.4
|
21.7
|
|
STC
|
Irradiance 1000 W/m², Cell Temperature 25°C, Air Mass AM1.5 according to EN 60904-3.
|
||||
|
MECHANICAL DATA
|
|
|
Solar cells
|
Monocrystalline
|
|
Cell configuration
|
130 cells (5×13+5×13)
|
|
Module dimensions
|
1894x1096x30mm
|
|
Weight
|
22.5kg
|
|
Superstrate
|
High Transmission, Low Iron, Tempered ARC Glass
|
|
Substrate
|
White Back-sheet
|
|
Frame
|
Anodized Aluminium Alloy type 6005-2T6, Black
|
|
J-Box
|
Potted, IP68, 1500VDC, 3 Schottky bypass diodes
|
|
Cables
|
4.0mm² (12AWG), Positive(+)350mm, Negative(-)230mm (Connector Included )
|
|
Connector
|
Risen Twinsel PV-SY02, IP68
|
